E-Bike
Motor
Motor
Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal
UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Battery
Specialized U2-530, alloy casing, state of charge display, 530Wh
Wiring Harness
Custom wire harness
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Frameset
Frame
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount
Seat Binder
Alloy, bolt-type, 34.9mm
Suspension
Fork
Fork
SR Suntour XCM32, 110mm travel, lockout
Brakes
Front Brake
Front Brake
Shimano BR-MT200, hydraulic disk, 180mm
Rear Brake
Shimano BR-MT200, hydraulic disk, 180mm
Drivetrain
Chainrings
Chainrings
Praxis, 36T, 104BCD
Shift Levers
Shimano Alivio, 9-speed w/ Optical Gear Display
Rear Derailleur
Shimano Alivio, SGS, 9-speed
Cassette
Shimano CS-HG400, 9-speed, 11-36t
Chain
KMC e9T, 9-speed w/ Missing Link™
Crankset
Custom alloy forged crankarms
Wheels & Tires
Rims
Rims
Stout XC 29, 25mm internal width, disk-specific
Front Hub
Shimano MT400, Centerlock, 15x100mm, 32h
Rear Hub
Shimano MT400-B, Centerlock, 12x148 Boost, 32h
Spokes
DT Swiss Industry
Front Tire
Ground Control, 2Bliss Ready, 29x2.35"
Rear Tire
Ground Control, 2Bliss Ready, 29x2.35"
Inner Tubes
Presta, 48mm valve
Cockpit
Stem
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL 750mm
Grips
Specialized Trail Grips, Lock-on
Saddle
Rivo Sport, steel rails, 155mm
SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Accessories
Pedals
Pedals
Specialized platform pedal
Bell
Simple bell
